Oil Water Separators
PRM Oil Water Separators provide high efficient fluid separation with low maintenance that can operate as standalone systems or used with integrated packages. These industrial-duty units are designed for flow rates from 1 to 100 GPM. Higher flow rates can be manufactured upon request.
Features
- Table-Mounted, Painted Steel Welded Frame
- Stainless Steel Welded Construction
- PVC Coalescing Media Pack
- Stainless Steel Media Anchor Hardware
- Adjustable PVC Oil Skimmer with Viton O-Rings
- Removable Lid with Stainless Steel Tee Bolts
- Vent Port, Sump Drain, Cleanout Port, and Oil Outlet Port
- Sludge and Grit Chamber with Manual Drain
Models
- OWS-10: 1-10 Gallons Per Minute
- OWS-20: 5-20 Gallons Per Minute
- OWS-30: 5-30 Gallons Per Minute
- OWS-40: 5-40 Gallons Per Minute
- OWS-60: 5-60 Gallons Per Minute
- OWS-80: 5-80 Gallons Per Minute
Options
- Alternate coalescing media CPVC or other
- Bag Filtration
- Sight Tube Assembly
- System Control Panel
- Equalization Tank
- Product Storage Tanks with H/L Switches
- Level Controls
Product Specifications
- 2” adjustable oil skimmer, outlet on both sides
- Two 1” air vents
- 2” wide gasket lid with easy turn retainers
Description
PRM Oil Water Separators are manufactured using heavy gauge 304 stainless steel and can be supplied with internal sumps or just the body only. Our field adjustable skimmers provide efficient separation for varying site conditions.
For applications with heavy solids loading we can incorporate slant rib clarification plates for precipitating solids into an integrated collection tank. An equalization surge tank is generally recommended prior to the oil water separator to optimize performance and insure separation especially with emulsified liquids. When designing the oil water separator it is good practice to size the system for the maximum potential flow rates.
